Products:

MMP 20A Speed Control               WIRELESS FORWARD/REVERSE SWITCH              MMP 25A Speed Control

Speed Controls:

(for brushed motors/gearmotors)

Downloads
Input Voltage
Continuous Current
Peak Current
Features
MMP 20A-12V-RSP

Spec Sheet

12 VDC
20 Amps

40 Amps

(1 sec)

IP-65 Ingress Protection, Integrated Reversing Switch & Speed Pot
MMP 20A-24V-RSP

Spec Sheet

24 VDC
20 Amps

40 Amps

(1 sec)

MMP 20A-48V-RSP

Spec Sheet

48 VDC
20 Amps

40 Amps

(1 sec)

MMP 25A-12V

Spec Sheet

12 VDC
25 Amps

40 Amps

(1 sec)

IP-65 Ingress Protection, Speed Pot on 16" leadwires
MMP 25A-24V

Spec Sheet

24 VDC
25 Amps

40 Amps

(1 sec)

MMP 25A-48V

Spec Sheet

48 VDC
25 Amps

40 Amps

(1 sec)

MMP 90V-10A-PWM

Spec Sheet

Operation Manual

115-230 VAC or 115-230 VDC
5 Amps

10 Amps

(with heatsink)

IR Comp, Min/Max Speed, Accel/Decel, Current Limit
MMP 16A-12.24V

Spec Sheet

10-32 VDC
16 Amps

35 Amps

(1 sec)

IR Comp, Min/Max Speed, Accel/Decel, Current Limit
MMP 30A-12.24V

Spec Sheet

8-32 VDC
15 Amps

30 Amps

(1 min)

IR Comp, Min/Max Speed, Accel/Decel, Current Limit



Wireless Forward/Reverse Switch:

(for brushed motors/gearmotors)

Downloads
Input Voltage
Continuous Current
Peak Current
Features
MMP RF40A-12V

Spec Sheet

12 VDC

40 Amps

(30 sec)

60 Amps

(1 sec)

  Wireless 150' Range, IP-67



MMP provides a full set of detailed specifications for every product we sell, for your approval.
It is the sole responsibility of the end user to protect the product from any electrical and/or physical damage.
It is also the sole responsibility of the end user to determine the suitability of the product for their own application.
MMP warrants all of our products against defects in material and workmanship for a full year following the shipment of the item.



Please note that the Products on our site are only samples of our total product offering.
We offer a multitude of finished designs that can likely meet your exact requirements.
If you are unable to find a product that meets your requirements, please contact us
and we will make a recommendation from our thousands of released designs.

"Midwest Motion Products can provide you with prototypes from stock, ultra-fast turnaround on most short run orders, and minimal lead-times for large-scale Production."
No Minimum Order Quantities.
